Stockists and Suppliers of Huge Range of Steel Metal Bar Products : Like Hot Rolled Bar / Cold Drawn Bar / Peeled Polished Bar / Forged Bar / Bright Bar / Flat Bar/ Square Bar / Tringular Bar / Round Bars / Hex Bars / Solid Bars / T Bar / Threaded Forged Bars Avialble in Stainless Steel / Alloy Steel / Nickel : Monel Hastelloy Inconel / Carbon Steel / Mild Steel Etc.Hot Rolled Bars / Cold Drawn Bars / Peeled Polished Bar / Forged Bar Alloy Steel BarEN19 – 709M40 Alloy Steel Bar
EN24 – 817M40 Alloy Steel Bar
EN26 – 826M40 Alloy Steel Bar
EN30B – 835M30 Alloy Steel Bar
EN36B – 655M13 Alloy Steel Bar Specification: EN19 – 709M40 |  Colour Code: Black
Availability:
Black Round Bar in “as rolled “ and hardened and tempered to condition “T”
Black rolled and forged surface: 16mm diameter to 350mm diameter
Bright Peeled Round Bar, “as rolled” and condition “T”: 16mm diameter to 160mm diameter Characteristics: This material distorts when machining shafts or long spindles, especially once hardened and tempered
In practice, the work pieces should be rough machined to plus tolerance and left in the open on the floor for 36 hours after which the material would have “aged” and stress relieved itself and thereby minimising distortion on the finishing of the product
Machinability is good but allow 6% on outside diameter for removal of surface defects
This material can be welded but welding should only be attempted by using the appropriate methods and materials as advised by welding expertise
Ideal for 60 ton tensile applications up to 100mm max
Sizes above limited ruling section will be heat treated to hardness only, with no guarantee on mechanical properties Applications:Utilised when higher than carbon steel mechanical properties are required
Commonly used for axles, drive shafts, crankshaft connecting rods, high tensile bolts, studs, propeller shaft joints, rifle barrels, and induction hardened pins
Bolt specification: 9.8 (in condition “T”)
Bolt specification: 10.9 (in condition “U”) Comparable Specifications: Din 42CrMo4
SAE 4240
Deutsche W/No 1.7225
Euro Norm EN 10083-1 (1991) 970 Part 1; 42CrMo4
BS970 Part 1 1983, 709M40
BS970 of 1955 EN19 Chemical Composition (%): | Carbon (C) | 0.36 (Min) – 0.44 (Max) | | Silicon (Si) | 0.10 (Min)- 0.40 (Max) | | Manganese (Mn) | 0.70 (Min) - 1.00 (Max) | | Chromium (Cr) | 0.90 (Min) – 1.20 (Max) | | Sulphur (S) | nil (Min) – 0.04 (Max) | | Phosphorus (P) | nil (Min)- 0.035 (Max) | | Molybdenum (Mo) | 0.25 (Min) – 0.35 (Max) |
Working and Heat Treatment: Forging:Forge within the temperature range of 1250C/900C Celsius
Anneal: Anneal at a temperature of 850C Celsius and cool steadily
Normalising:not applicable
Hardening:oil quench from a temperature of 850C/880C Celsius Mechanical Properties: | Annealed | R | S | T | U | V | W | Y | | Ruling Section (mm) | 150 | 150 | 100 | 65 | 65 | 30 | 30 | 25 | | Tensile Strength (MPa) | 680/720 | 690/850 | 770/930 | 850/1000 | 930/1080 | 1000/1160 | 1080/1240 | 1280 | | Yield Stress (MPa) | 440/480 | 480 | 570 | 665 | 740 | 835 | 895 | 1050 | | Elongation (% Min) | 22 | 15 | 15 | 13 | 12 | 12 | 10 | 10 | | ISO V Impact (Joule) | 30 | 30 | 30 | 30 | 25 | 25 | 22 | 7 | | Hardness (Brinell) | 190/210 | 201/255 | 223/277 | 248/302 | 269/321 | 293/341 | 311/375 | 363/415 | | Proof Stress (0.2%) if required (MPa, Min) | | 495 | 550 | 630 | 710 | 770 | 850 | 985 |
|
